Nitinol Stone Extractor Baskets


Availability:

Quantity:



Inquire Add to Basket

Following ASTM F2063 or GB 24627-2009, subdividing the specific performance requirements of wires for different applications, the proportion of each element is precisely controlled duringsmelting. The wire is available for various applications, such as guide wire, basket, stent, etc. The product has been verified to be safe and reliable by the bio-compatibility test.

Product Description

Composiyion	Component(at%)	Impurity content
Composiyion	Component(at%)	C - wt %	0 - wt %	H − wt %
NT - M	Ti - 50.8Ni	≤0.04	≤0.04	≤0.005
NT - S	Ti - 50.0Ni	≤0.04	≤0.04	≤0.005
NT - E	Ti - 50.9Ni	≤0.04	≤0.04	≤0.005
NTN	Ni47T44Nb9	≤0.05	≤0.05	≤0.01
NTF	Ni47Ti50Fe3	≤0.05	≤0.05	≤0.01

NiTi Wire		NiTi rope
Wire range	Tolerance range	Construction	Diameter range
0.05-0.10	+0.008	1X3	0.10-1.00
0.10-0.50	+0.010	1X7	0.15-1.00
0.50-1.00	+0.015	1X19	0.30-2.00
1.00-2.00	+0.020	3X3	0.30-1.20
2.00-4.00	±0.025	7X7	0.50-2.00

Nitinol Medical wire rope 1x7 Control Cable Snare
